YJD-A star discharge means is ash dust removal equipment, major equipment supply and other equipment for materials for powder materials and granular materials. YJD-A star unloader is widely used in environmental protection, metallurgy, chemical industry, food, food and other industrial sectors.

YJD-A star unloader also known as electric cinder valve, turn its composition and the dragon unloader three parts by the motor, teeth difference planetary gear unit (X) or a pin wheel cycloidal reducer (Z). There are two series of 60 kinds of specifications. Importers square flange type A stripper, round for B-type unloader.

YJD-A star unloader works:

When the star unloader work, dust falls by gravity, full top and side of the star-shaped blade spaces. Rotating blade rotor shaft driven by a motor through reducer, the lower portion of the impeller to remove the dust by its own weight.

YJD-B star discharge commonly used in pneumatic output system, the pressure output system or negative output system, star discharge can be uniformly and continuously fed to the conveying pipe. To ensure that the gas inside the pneumatic output tube, solid stable, so that the pneumatic conveying can work at the same time, but also the upper and lower discharge pressure off the air lock and play a role. Therefore, star discharge is an important component of pneumatic conveying systems commonly used.

Temperature YJD-B-type star unloader its temperature transport of materials up to 280 ° C at both ends of the bearing and the impeller there is a certain isolation, to prevent contact with the bearing ultra-fine powder. Temperature heat unloader transport of materials up to 500 ° C, using sprocket connection. And unloading gear housing there is a certain distance.

YJD-B star discharge can be used to collect material system, as a silo unloader. Star unloader is currently the most advanced unloading device, commonly used in dust removal system as one of the important equipment dust removal system. It is particularly suitable for dust, small particles of material, by the environmental protection, metallurgy, chemical, food, cement, road building, drying equipment and other industries projects based on merit. When the upper silo material fall by gravity filling in the gap between the blade, with rotating blades in the lower portion of unloading. Therefore, star discharge can be quantitatively and continuously discharge.
