DMF-Z-40S rectangular electromagnetic pulse valve details
          Electromagnetic pulse valve is a right-angle valve, angle between import and export is 90 °, suitable for mounting air bag is connected with the dust blowing tube. Airflow, can provide cleaning gas pulses to meet the requirements. Department abroad (also called diaphragm valve) is a pulse jet bag filter cleaning system of compressed air "switch" controlled by pulse jet control device output signal of the filter bag row by row (room) injection cleaning, precipitator resistance remains within the set range, in order to ensure that processing power and dust collection efficiency.
        DMF-Z-type electromagnetic pulse valve
       Description: Working pressure: 0.4 to 0.7, ambient temperature: -10 ~ 55 (℃), the use of media: clean air, diaphragm life: blowing than 100 million times.
Connecting thread: ZG1 ", length: 110mm, width: 85mm, height: 125mm, weight: 0.75kg
installation method:
Electromagnetic pulse valve input terminal (IN), connected to the accumulator metal pipe whose output is connected to the blowing dust box tube connecting thread between are filled with tetrafluoroethylene raw material belt tight.
The electromagnetic pulse valve: the oil is to control the size of the oil pressure.
Press and inlet valve in the form of import and export point of view can be divided into three types:
        a) rectangular electromagnetic pulse valve: the import and export right angles to, directly affected by the signal diaphragm valve control;
b) straight-through electromagnetic pulse valve: the valve body import and export into 180 degrees, directly controlled by the signal diaphragm valve;
c) submerged electromagnetic pulse valve: air inlet submerged in the air bag, directly controlled by the signal diaphragm valve.
Electromagnetic pulse valve technical requirements:
    1, the product of working pressure of 0.1MPa ~ 0.7MPa, medium degreasing, in addition to air treatment.
    2, in the product nominal air pressure state, the solenoid valve operating voltage is 85% of rated voltage, open the electromagnetic pulse valve response time should be less than 0.03s.
    3, working air pressure at 0.1MPa, can make the pulse valve closed.
    4, the product should be able to withstand air pressure of 0.8MPa.
    5, under specified environmental conditions, the electromagnetic coil housing insulation resistance should be greater than 1MΩ. The company mainly engaged in Henan DMF-Z-40S electromagnetic pulse valve sales, the solenoid valve supply wholesale and sales.
    6, at room temperature 5 degrees to 35 degrees, relative humidity less than 85%, the electromagnetic coil casing can withstand voltage 50Hz, 250V, which lasted 1min no breakdown.
    7, electromagnetic pulse valve withstand a frequency of 20Hz, the full amplitude of 2mm, the vibration lasted 30min after should be able to work properly.
    8, under normal conditions of use, lifetime cumulative patch should more than 80 million times.
    9, the valve look no coating peeling, scratches, burrs and other damage.
