DMF-T straight-through electromagnetic pulse valve import and export center of the same line, it is suitable for mounting air reservoir is connected with the dust blowing tube, air flow, to meet the requirements of the pulse cleaning air flow.
DMF-T straight-through electromagnetic pulse valve is composed of solenoid pilot valve and the main valve in two parts, when energized, the iron core is drawn from the electromagnetic force open the pilot valve port, the media pressure on the diaphragm chamber drops and the valve inlet side pressure drop, due to an increase compared to the inlet end of the pressure valve, the diaphragm pushing the medium into the outlet end of the valve in an open state. When the power failure, the core is reset gravity and spring, the pilot valve port closed, the diaphragm upper chamber pressure increases, the diaphragm is pushed down to close the mouth of the main valve, then the valve was closed.
DMF-T-70 electromagnetic pulse valve is a valve so called straight-through electromagnetic pulse valve, import and export center for the same straight line, and its inlet and gas pipe connected to the outlet pipe is connected with the injection, air flow, can provide compliant required pulse stream. And air box pulse bag filter supporting the use.
Working pressure: 0 3-0 6Mpa Working medium: clean air
Voltage: Dc24v / Ac220v Current: 800mA / 60mA
Environment: a temperature of 10 ℃ ~ 55 ℃ relative air temperature does not exceed 85%
Straight-through electromagnetic pulse valve diaphragm life: 100 million times or 2 to 3 years
